Description & Features
Overview
The Lynx L6-2 puts two warning heads and a wide 120-degree Linear beam in a 9.5-inch housing. Its twelve Generation V 3-watt LEDs deliver SAE J595 Class 1 warning performance for compact dash, window, rear-deck and suitable exterior installations. Select from 36 patterns, including wig-wag, strobe and steady-on, and save two favorites with Dual Memory. Choose one of 13 fixed-color arrangements, with six LEDs of each color on split versions. Add circuit-board waterproofing for exterior use.
- 12 Generation V 3-watt LEDs, with six LEDs in each of two heads.
- Meets or exceeds SAE J595 Class 1 warning-light performance requirements.
- 36 selectable patterns.
- Dual Memory saves two favorite patterns independently.
- Both saved patterns remain after a complete power disconnect.
- Wig-wag, strobe and steady-on functions.
- Linear lenses provide a wide 120-degree beam.
- 9.5 × 2 × 1.5-inch bare housing; weighs 1.9 lb.
- 13 fixed-color options: five solid and eight split.
- 12V DC operation, with a 12-18V operating range.
- 0.5 A flashing draw and 2.5 A steady-on draw at 12V.
- Built-in flasher; no separate flasher module needed.
- Synchronizes with current Lynx T6 and L6 lights.
- Two L brackets and four bracket screws included.
- 10-foot, 14 AWG power cable included.
- Optional cigarette-lighter plug includes a Dual Memory switch, pattern button and fuse.
- Optional suction cups and flashback guard for mounting behind glass.
- Optional circuit-board waterproofing required for exterior use.
- Free 5-year warranty included as standard.
Light Output & Visibility
The L6-2 combines two adjacent heads with Linear lenses that spread light across a 120-degree beam. It gives you more LEDs in one housing than the single-head L6-1 while keeping the installation shorter than an 18-inch L6-4. The beam angle and housing length describe different things: the lenses control optical spread, while the housing determines how much mounting space you need.
Check both heads from outside the vehicle, including the angled approaches you want to cover. A window pillar or nearby equipment may hide one head even when the other remains visible. That matters especially on a split-color bar, where each color occupies its own head. Tint and glass angle affect visible output; check daylight and nighttime visibility and add the optional flashback guard to reduce cabin reflections.
An anodized aluminum housing and scratch- and shatter-resistant polycarbonate lenses protect the assembly. Individual LED modules are replaceable, with spare parts available from ETD. A damaged head can be serviced without automatically replacing the entire light bar.
Color Options
The L6-2 has 13 fixed-color arrangements: five solid colors and eight split combinations. A solid version uses the same color in both heads. A split version puts one color in each head, with six LEDs per color. This gives the two colors separate positions across the 9.5-inch bar.
| Arrangement | Available colors | Two-head arrangement |
|---|---|---|
| Solid (5) | White, Red, Blue, Amber, Green | Both heads the same color |
| Split (8) | Red/White, Blue/White, Red/Blue, Amber/White, Green/Amber, Red/Amber, Blue/Amber, Green/White | One color per head; 6 LEDs each |
For example, red/blue means one six-LED red head beside one six-LED blue head. The LEDs keep those colors when you change patterns. If a particular color must be on a specific side, confirm orientation with ETD before ordering. Select colors authorized for your vehicle and role.
Recommended Uses & Limitations
The L6-2 suits first responders, fleet managers and POV owners who want two warning heads in a compact housing. Possible locations include a patrol vehicle's rear deck, a fire or rescue vehicle's window, or a suitable mounting point on a tow, utility, construction or security vehicle. Its broad Linear beam is useful when the installation calls for viewing from angled approaches as well as directly ahead.
One L6-2 keeps two heads together in a single assembly. A pair can provide separate mounting positions when equipment or a rear-window brake light divides the available space. Current Lynx L6 and T6 lights can synchronize through dedicated sync wires. Plan additional warning lights for approaches this bar does not face; exterior mounting requires the circuit-board waterproofing upgrade.
Compare housing sizes and lens types in our interior and exterior LED warning bars.
Technical Specifications
Lighting
| Specification | Lynx L6-2 |
|---|---|
| Heads / LED count | 2 heads / 12 LEDs; 6 LEDs per head |
| LED generation / rating | Generation V / 3 W per LED |
| Combined LED rating | 36 W (12 × 3 W) |
| Optics / beam angle | Linear / 120 degrees |
| Color arrangements | 13 total: 5 solid, 8 split |
| Published LED life | 100,000 hours; LED specification, not a total product-life guarantee |
Power
| Specification | Lynx L6-2 |
|---|---|
| Nominal voltage / operating range | 12V DC / 12-18V DC |
| Flashing current at 12V | 0.5 A |
| Steady-on current at 12V | 2.5 A |
| Fuse for one unit | 5 A |
| Included power cable | 10 feet / 14 AWG |
| Standard connection | Hardwire |
| Optional controls | Inline switch; cigarette-lighter plug with Dual Memory switch and pattern-change button |
| Fuse inclusion | Included with optional cigarette-lighter plug; otherwise purchased separately |
| Flasher | Built in |
| Electrical protection | Reverse-polarity and overvoltage protection |
Physical & Compliance
| Specification | Lynx L6-2 |
|---|---|
| Bare housing (length × depth × height) | 9.5 × 2 × 1.5 inches; excludes brackets and cable |
| Product weight | 1.9 lb |
| Housing / lens material | Anodized aluminum / polycarbonate |
| Light-head and housing protection | IP67 |
| Circuit-board protection | Optional waterproofing upgrade brings circuit-board protection to IP67; select for exterior mounting |
| Operating temperature | -30°C to +65°C / -22°F to +149°F |
| Serviceability | Replaceable LED modules; spare parts available |
| Warranty | Free 5-year warranty included as standard |
The Lynx L6-2 meets or exceeds SAE J595 Class 1, California Title 13, ECE R65, CISPR 25 Class 3, SAE J1455 and RoHS requirements. These cover warning-light performance, electromagnetic emissions, vehicle environmental performance and restricted substances, as applicable. CISPR 25 Class 3 addresses electromagnetic emissions; it is not a promise of zero interference with every radio installation.
Patterns & Functions
| Function | Operation |
|---|---|
| Selectable patterns | 36 |
| Warning functions | Wig-wag, strobe and steady-on |
| Optional memory control | Cigarette-lighter plug can power either saved setting and change patterns |
| Dual Memory | Two independently saved pattern settings |
| Memory retention | Both settings retained after power disconnect |
| Synchronization | Dedicated sync wire; compatible with current Lynx T6 and L6 series |
| Older-series compatibility | Does not synchronize with T4-series lights |
Included in Box
Included Items
| Item | Quantity |
|---|---|
| Lynx L6-2 light bar | 1 |
| L mounting brackets | 2 |
| Bracket screws | 4 |
| 10-foot, 14 AWG power cable | 1 |
Optional Accessories Sold Separately
The optional cigarette-lighter control plug includes the Dual Memory switch, pattern-change button and a fuse. An inline switch, suction cups, flashback guard, headliner brackets for visor mounting and an additional 10 feet of wire are available separately. The extra wire extends the supplied cable; it does not replace it. Suction cups and the flashback guard can be used together.
Circuit-board waterproofing is an optional upgrade for exterior mounting. The light heads and housing already have IP67 protection; the upgrade adds IP67 protection to the circuit board. Waterproofing does not restrict your color or mounting choice. For hardwiring, purchase the required 5 A fuse and suitable fuse holder separately.
Installation & Wiring Instructions, Fitment, Mounting Locations & Options
Installation and Wiring Instructions
Use the L6-2 installation instructions or Download the L6-2 installation PDF for wiring and operating steps.
Have a qualified installer handle vehicle-specific wiring and mounting. For product-operation questions, email customerservice@extremetacticaldynamics.com with your model and order number.
Dash, Windshield and Rear-Deck Mounting
Allow room for the 9.5 × 2 × 1.5-inch bare housing plus brackets, accessories and cable routing. The L6-2 weighs 1.9 lb. Measure the clear space at the intended mounting position, not simply the overall window width, and make sure both heads remain visible.
The included L brackets suit rear-deck mounting and other appropriate surfaces. Optional suction cups allow removable installation against a suitable front, rear or side window and can be used with the flashback guard. Check the view from outside at different angles and keep the light clear of the driver's sightline. If a third brake light or other equipment separates two mounting areas, individual L6-2 units can be positioned on either side without covering that equipment.
Exterior and Other Mounting Options
For a suitable push bumper, headache rack or other exterior location, use the supplied L brackets and choose circuit-board waterproofing. Keep the heads clear of nearby vehicle parts that could block their beam. Protect connections and route the cable away from sharp edges and moving parts. The four included screws attach the brackets to the light; vehicle attachment hardware must suit the mounting surface.
Optional headliner brackets support visor or headliner mounting where the full 9.5-inch housing and its hardware fit securely. A B-pillar or cage may provide another location when space and attachment points are suitable. Keep the light and wiring clear of airbags, controls and the driver's view.
Power and Controls
Hardwire the L6-2 to a fused 12V DC supply, or add the optional cigarette-lighter plug for plug-in operation. Use a 5 A fuse for one L6-2. The optional plug includes a fuse; hardwired installations require separately purchased fuse protection. An inline switch is also available separately.
The optional control plug lets you power either saved memory setting and change patterns with its pattern-change button. Both saved selections remain after unplugging. To coordinate multiple lights, use the dedicated sync connection with current Lynx T6 or L6 models; older T4 units are not compatible.
Compare Models
The L6-2 is the compact two-head model in the Linear lineup. All five sizes use 120-degree Linear lenses; choose the housing length and number of heads for your available mounting space.
| Model | Heads / LEDs | Length | Key function / difference | Best fit |
|---|---|---|---|---|
| Lynx L6-1 | 1 / 6 | 4.75 in | Single-head compact warning light | Very tight mounting positions |
| Lynx L6-2 | 2 / 12 | 9.5 in | Compact two-head warning light | Dash, deck and paired installations |
| Lynx L6-4 | 4 / 24 | 18 in | Four-head warning; left/right patterns | Rear decks and push bumpers with room for an 18-inch bar |
| Lynx L6-6 | 6 / 36 | 27 in | Wider housing; left/right/center-out patterns | Wider rear-window applications |
| Lynx L6-8 | 8 / 48 | 35 5/8 in | Longest housing in this lineup; left/right/center-out patterns | Broad rear-window coverage where the bar fits |
Choose the L6-2 when you want two heads together in 9.5 inches. The 4.75-inch L6-1 fits a smaller position and uses three LEDs per color in a split head; the L6-2 gives each color a separate six-LED head. Step up to the 18-inch L6-4 for four heads and selectable left/right patterns, or compare the longer L6-6 and L6-8 when more mounting width is available.
The T6-2 matches the L6-2 in dimensions, LED count, current draw, colors, functions and accessories. The only specification difference is its focused 40-degree TIR lenses in place of the L6-2's 120-degree Linear lenses. Choose the optical spread for the approaches you want to cover. The other matched pairs are L6-1/T6-1, L6-4/T6-4, L6-6/T6-6 and L6-8/T6-8.
Frequently Asked Questions
Should I choose the L6-2 or the T6-2?
Choose the L6-2 for a 120-degree Linear beam or the T6-2 for a focused 40-degree TIR beam. Both have 12 LEDs in a 9.5-inch housing, with the same patterns, Dual Memory, current draw and accessories. The lens choice changes the optical spread, not the mounting dimensions.
Is the standard L6-2 waterproof?
The light heads and housing have IP67 protection as standard. For exterior use, select the optional circuit-board waterproofing upgrade. This applies to push-bumper, headache-rack and other exterior installations.
Can I mount two L6-2 lights on my rear deck?
Yes, if each position has room for the housing, mounting hardware and cable route. Two units let you work around a center brake light or equipment while keeping both heads on each unit visible. Use the dedicated sync connection to coordinate their patterns, and follow the installation guide for wiring.
Does a split-color L6-2 change colors?
No. Each head has a fixed color. A red/blue L6-2 has six red LEDs in one head and six blue LEDs in the other. Pattern selection changes the flashing sequence, not the colors. A solid version uses the same color in both heads.
Can the optional plug operate both memory settings?
Yes. The optional cigarette-lighter plug has a Dual Memory switch that lets you power either saved setting, plus a pattern-change button. It also includes a fuse.
Can the L6-2 synchronize with TIR lights?
Yes. Current Lynx L6 and T6 lights can synchronize through the dedicated sync wire, so the different lens types do not prevent synchronization. Older T4-series lights are not compatible.
How much power does it draw, and will it drain my battery?
The L6-2 draws 0.5 A while flashing and 2.5 A on steady-on at 12V. Use these current figures when planning the electrical load. Operation with the engine off can discharge the battery; runtime depends on battery condition, capacity and other equipment drawing power.
Does it need an external flasher?
No. The flasher is built into the light. Hardwiring requires a fused power connection and suitable controls; the optional inline switch and cigarette-lighter control plug are sold separately.
Are the brackets included in the dimensions?
No. The 9.5 × 2 × 1.5-inch measurements describe the bare housing. Allow extra space for brackets, accessories and cable routing. The light weighs 1.9 lb.
Can I replace one LED module?
Yes. The L6-2's individual LED modules are replaceable, and spare parts are available from ETD. Contact us with your model and the part you need.
